Sonic Blower
Sonic 70 Centrifugal Blower
|
PERFORMANCE RANGE: Flow: 70-700 SCFM (120-1200 m3/hr) |
Pressure: 0.5-3.5 PSIG (35-241mbar) Vacuum: 1.0-6.6"Hg (34-224mbar) |
| Standard Features: | Options: |
| • Auto Belt Tensioner (PATENT PENDING) | • High inlet temperature (400 F) |
| • Multiple mounting configurations | • Thermocouple for PLC monitoring |
| • Small size and footprint | • Wash down, explosion proof, |
| • Adaptable to IEC & NEMA motors | chemical duty motors |
| • Lightweight aluminum construction | • Hydraulic, pneumatic motors & PTO |
| • Welded flange inlet and outlet |
Sonic 85 Centrifugal Blower
|
PERFORMANCE RANGE: Flow: 85-850 SCFM (144-1444 m3/hr) |
Pressure: 0.5-3.75 PSIG (35-259mbar) Vacuum: 1.0-7.0"Hg (34-224mbar) |
| Standard Features: | Options: |
| • Auto Belt Tensioner (PATENT PENDING) | • High inlet temperature (400 F) |
| • Multiple mounting configurations | • Thermocouple for PLC monitoring |
| • Small size and footprint | • Wash down, explosion proof, |
| • Adaptable to IEC & NEMA motors | chemical duty motors |
| • Lightweight aluminum construction | • Hydraulic, pneumatic motors & PTO |
| • Welded flange inlet and outlet |
Sonic 100 Centrifugal Blower
|
PERFORMANCE RANGE: Flow: 100-1000 SCFM (170-1700 m3/hr) |
Pressure: 0.5-3.5 PSIG(35-241mbar) Vacuum: 1.0-6.6" Hg (34-224 mbar) |
| Standard Features: | Options: |
| • Auto Belt Tensioner (PATENT PENDING) | • High inlet temperature (400 F) |
| • Multiple mounting configurations | • Thermocouple for PLC monitoring |
| • Small size and footprint | • Wash down, explosion proof, |
| • Adaptable to IEC & NEMA motors | chemical duty motors |
| • Lightweight aluminum construction | • Hydraulic, pneumatic motors & PTO |
| • Welded flange inlet and outlet |
Sonic 150 Centrifugal Blower
|
PERFORMANCE RANGE: Flow: 150-1250 SCFM (255-2124 m3/hr) |
Pressure: 0.5-4.2 PSIG (35-290 mbar) Vacuum: 1.0-8.1 Hg (34-270 mbar) |
| Standard Features: | Options: |
| • Auto Belt Tensioner (PATENT PENDING) | • High inlet temperature (400 F) |
| • Multiple mounting configurations | • Thermocouple for PLC monitoring |
| • Small size and footprint | • Wash down, explosion proof, |
| • Adaptable to IEC & NEMA motors | chemical duty motors |
| • Lightweight aluminum construction | • Hydraulic, pneumatic motors & PTO |
| • Welded flange inlet and outlet |
Sonic 200 Centrifugal Blower
|
PERFORMANCE RANGE: Flow: 200-2000 SCFM (340-3400 m3/hr) |
Pressure: 0.5-3.5 PSIG (35-241mbar) Vacuum: 1.0-6.6" Hg (34-224 mbar) |
| Standard Features: | Options: |
| • Auto Belt Tensioner (PATENT PENDING) | • High inlet temperature (400 F) |
| • Multiple mounting configurations | • Thermocouple for PLC monitoring |
| • Small size and footprint | • Wash down, explosion proof, |
| • Adaptable to IEC & NEMA motors | chemical duty motors |
| • Lightweight aluminum construction | • Hydraulic, pneumatic motors & PTO |
| • Welded flange inlet and outlet |
Sonic 300 Centrifugal Blower
|
PERFORMANCE RANGE: Flow: 300-2500 SCFM (510-4248 m3/hr) |
Pressure: 0.5-4.2 PSIG (35-290 mbar) Vacuum: 1.0-8.1" Hg (34-270 mbar) |
| Standard Features: | Options: |
| • Auto Belt Tensioner (PATENT PENDING) | • High inlet temperature (400 F) |
| • Multiple mounting configurations | • Thermocouple for PLC monitoring |
| • Small size and footprint | • Wash down, explosion proof, |
| • Adaptable to IEC & NEMA motors | chemical duty motors |
| • Lightweight aluminum construction | • Hydraulic, pneumatic motors & PTO |
| • Welded flange inlet and outlet |
Sonic 350 Centrifugal Blower
|
PERFORMANCE RANGE: Flow: 350-3500 SCFM (595-5950 m3/hr) |
Pressure: 0.5-3.5 PSIG (35-241 mbar) Vacuum: 1.0-6.6" Hg (34-224 mbar) |
| Standard Features: | |
| • Multiple mounting configurations | |
| • Small size and footprint | |
| • Adaptable to IEC & NEMA motors |
Sonic 350 DD Centrifugal Blower
|
PERFORMANCE RANGE: Flow: 350-2800 SCFM (595-5950 m3/hr) |
Pressure: 0.5 to 2.5 PSIG (173 mbar) Vacuum: 1.0 to 4.0 Hg (136 mbar) |
| Standard Features: | |
| • Multiple mounting configurations | |
| • Small size and footprint | |
| • Adaptable to IEC & NEMA motors |
Sonic Centrifugal Blower with Welded Inlet & Outlet Flanges
|
PERFORMANCE RANGE: See Models 70, 100, 150, 200 & 300. |
| Standard Features: | Options: |
| • Fully welded 4" #150 flanges | • High inlet temperature (400 F) |
| • Dual PTFE shaft seals | • Thermocouple for PLC monitoring |
| • Automatic belt tensioner | • Wash down, explosion proof, |
| • Multiple mounting configurations | chemical duty motors |
| • Small size and footprint | • Hydraulic, pneumatic motors & PTO |
| • Adaptable to IEC & NEMA motors | • Assorted blower coatings |
| • Lightweight aluminum construction |
Sonic Centrifugal Blower with Hydraulic Motor
|
PERFORMANCE RANGE: See Models 70, 100, 150, 200 & 300. |
| Standard Features: | Options: |
| • Low starting torque | • High inlet temperature (400 F) |
| • Automatic belt tensioner | • Thermocouple for PLC monitoring |
| • Multiple mounting configurations | • Assorted blower coatings |
| • Small size and footprint | |
| • Lightweight aluminum construction |
